Section J Building Fabric, Glazing and Sealing Guide

For a Section J Deemed-to-Satisfy assessment, the building envelope should first be defined around the relevant conditioned spaces.

The assessment may then need to consider:

• roof and ceiling construction;
• external and internal envelope walls;
• ground, suspended and exposed floors;
• complete wall and glazing performance;
• window and glazed-door areas;
• complete-system U-values and SHGCs;
• façade orientation and external shading;
• insulation continuity and buildability;
• operable windows and external doors;
• entrances, penetrations and exhaust openings; and
• the consistency of the report, drawings, schedules and specifications.

Under NCC 2022, walls and glazing are considered together as wall–glazing construction within the Deemed-to-Satisfy building-fabric provisions. Building sealing is addressed separately but should still be coordinated with the same envelope boundary.

The exact requirements depend on the building classification, climate zone, applicable NCC edition, jurisdiction, project scope and selected compliance pathway.



The thermal performance of a commercial building is not determined by one product or construction element.

Heat can move through roofs, walls, floors, glazing, doors and junctions. Solar radiation enters through glazing and can increase internal heat gains. Uncontrolled air leakage can allow conditioned air to escape or outside air to enter.

These effects are connected. A façade with extensive glazing may require a different combination of wall construction, glazing performance and shading from a façade with a high proportion of insulated opaque wall.

The project documentation should therefore communicate a coordinated response rather than a collection of disconnected requirements.

A coordinated envelope strategy should establish:

• where the conditioned envelope begins and ends;
• which walls, roofs and floors form part of that envelope;
• how the construction systems achieve the assessed thermal performance;
• which glazing systems are proposed on each façade;
• how orientation and shading affect the façade response;
• which openings need to be sealed;
• how insulation and sealing remain continuous at junctions; and
• where each requirement appears in the drawings and specifications.

For a broader explanation of the Section J framework, visit the Section J Knowledge Hub.

Before insulation or glazing performance can be assessed, the project team needs to establish which building elements form the envelope around the relevant conditioned spaces.

The envelope is not always identical to the external outline of the building.

It may include construction separating conditioned spaces from:

• outside air;
• the ground;
• unconditioned warehouses or storage areas;
• car parks;
• plant rooms;
• roof spaces;
• loading areas;
• unconditioned circulation spaces; or
• other parts of a mixed-use building.

This means some internal walls, floors or ceilings can form part of the thermal envelope where they separate a conditioned area from an unconditioned area.

The envelope boundary should be coordinated between the architectural and mechanical documentation. If the architect and mechanical consultant identify different conditioned zones, the fabric and services assessments may be based on different buildings.

Before the assessment is finalised, check that:

• conditioned and unconditioned rooms are clearly identified;
• the boundary is continuous across plans and sections;
• roofs, walls and floors along the boundary are documented;
• mixed-use and common areas are treated consistently;
• plant rooms and car parks are correctly classified as conditioned or unconditioned; and
• the mechanical zoning aligns with the architectural room uses.

An incorrect envelope boundary can lead to relevant construction being omitted, irrelevant construction being assessed or insulation being shown in the wrong location.



The roof or ceiling forming part of the envelope can be one of the building’s largest heat-transfer surfaces.

The assessment should be based on the complete roof or ceiling construction rather than on an insulation product considered in isolation.

Relevant information may include:

• roof cladding or membrane;
• roof colour or solar absorptance where relevant;
• roof and ceiling cavities;
• insulation type, thickness and location;
• framing and support systems;
• plasterboard or suspended ceilings;
• roof lights and other penetrations;
• services occupying the insulation zone;
• conditioned and unconditioned roof spaces; and
• junctions between roof and wall construction.

A note stating only an insulation R-value may not be enough to describe the assessed system. The drawings should also show whether the insulation is installed at roof level, ceiling level or within another part of the assembly.

The project team should confirm that the proposed material can be installed continuously around framing, services, roof lights and other interruptions.

Where roof or ceiling construction changes across the building, each relevant type should be clearly identified on the plans, sections and schedules.



External and internal envelope walls should be assessed using the complete construction build-up.

A wall can include cladding, cavities, membranes, framing, insulation, masonry, concrete, plasterboard and internal linings. Each layer can affect the total thermal response.

The documentation should identify:

• each wall type forming part of the envelope;
• the thickness and material of each layer;
• the position of insulation;
• the framing type and spacing where relevant;
• cavity dimensions;
• thermal breaks where applicable;
• interfaces with windows and doors;
• interfaces with roofs and floors;
• changes in construction around different parts of the façade; and
• internal envelope walls adjoining unconditioned areas.

The nominal R-value printed on an insulation product is not necessarily the same as the Total R-Value of the completed wall.

Framing and repeating thermal paths can reduce the overall performance of the assembly. This is particularly relevant for lightweight steel-framed walls, façade framing and other systems where conductive components interrupt the insulation layer.

Insulation should also be physically achievable within the proposed build-up. Increasing the scheduled R-value without checking the cavity depth, framing and coordination with fire or acoustic systems can create an impractical construction requirement.

A reliable solution should satisfy the applicable assessment requirements and remain buildable, documentable and procurable.



Floors can be overlooked when the design team focuses primarily on roofs, walls and glazing.

The relevant floor response depends on how the floor relates to the ground, outside air and adjoining conditioned or unconditioned spaces.

The assessment may need to distinguish between:

• slabs on ground;
• suspended floors over outside air;
• floors over open car parks;
• floors over unconditioned storage or plant areas;
• floors between conditioned spaces;
• floors adjoining mixed-use areas; and
• slab edges or other relevant thermal junctions.

The architectural sections should make these relationships clear. A floor appearing internal on a floor plan may still form part of the envelope when viewed in section.

Where insulation is required, its location and installation method should be coordinated with the structure, fire protection, soffit finishes and building services.

Under the NCC 2022 Deemed-to-Satisfy provisions, the performance of relevant walls and glazing is considered through the wall–glazing construction.

This is important because glazing is not assessed only as a standalone product. The result is influenced by the relationship between the opaque wall and glazed portions of the façade.

The assessment may consider:

• total wall area;
• total glazing area;
• wall construction performance;
• complete-system glazing performance;
• frame performance;
• façade orientation;
• solar heat gain;
• external shading;
• display glazing;
• curtain-wall and shopfront systems; and
• internal wall–glazing construction that forms part of the envelope.

The combined wall–glazing construction is assessed for heat transfer through the Total System U-Value. Externally facing wall–glazing construction may also need to satisfy the applicable solar-admittance requirements.

This means that increasing wall insulation alone may not resolve a façade with extensive or poorly performing glazing. Likewise, reducing glazing or improving shading can sometimes change the façade response without applying the same premium glazing system everywhere.

The applicable calculation method, limits and state or territory variations should be checked against the NCC edition and jurisdiction governing the project.



Descriptions such as single glazing, double glazing, low-e glass or tinted glass do not establish compliance on their own.

The assessor commonly needs performance information for the complete window or glazed-door system, including the glass and frame.

U-value

The U-value describes the rate of heat transfer through the system. A lower U-value generally indicates less heat transfer.

The complete-system value includes the influence of the glazing and frame. A centre-of-glass value should not be substituted for a whole-window value unless the applicable assessment method specifically permits that information.

Solar Heat Gain Coefficient

The Solar Heat Gain Coefficient, or SHGC, describes the proportion of incident solar radiation admitted through the glazing system.

A lower SHGC can reduce solar heat gain, but the most suitable value depends on the façade orientation, climate, shading, glazed area and overall design strategy.

Frame performance

Aluminium, thermally broken aluminium, timber, uPVC and other frame systems can produce different complete-system results even where the same glass is used.

The window schedule should therefore identify enough information to connect the assessed values with the proposed system.

Glazed doors, shopfronts and curtain walls

Glazed doors, shopfronts, curtain walls and display glazing should not be omitted merely because they are not labelled as conventional windows.

The drawings and schedules should distinguish transparent glazing, opaque spandrel zones, framing and other façade components so the correct areas and performance values can be assessed.



The quantity and location of glazing can be as important as the selected product.

A window schedule may contain suitable performance values while the assessment remains incorrect if the opening sizes, tags or orientations do not match the elevations.

The project team should verify that:

• each opening has a consistent tag;
• dimensions match between plans, elevations and schedules;
• glazed doors are included;
• curtain-wall areas are measured correctly;
• spandrel zones are separated from transparent glazing;
• roof lights are identified separately;
• each opening is assigned to the correct façade orientation;
• existing and proposed glazing are clearly distinguished; and
• later design changes are reflected in the assessment.

Orientation matters because solar exposure differs across the building. The same glazing system may not produce the same result on every façade.

A targeted façade response can therefore be more practical than specifying one glazing system universally without considering orientation, area and shading.

External shading can reduce the solar radiation reaching glazing and may form an important part of the wall–glazing compliance strategy.

Potential shading elements include:

• eaves;
• horizontal awnings;
• balconies;
• vertical fins;
• façade screens;
• deep window reveals;
• permanent projections; and
• other fixed architectural elements.

For assessment purposes, the element should be permanent, dimensioned and connected clearly to the relevant glazing.

A perspective image showing an apparent overhang may not provide enough information. The assessor may need the projection depth, position above the opening, opening height and relationship between the shading element and glazing.

Shading should also be assessed according to orientation. A horizontal projection may interact differently with northern, eastern and western solar exposure.

The architectural design should not introduce shading solely as a calculation device if the element is unlikely to remain in the approved and constructed building.

Any shading relied upon in the assessment should appear clearly in the final elevations, sections and façade details.



Building sealing is intended to limit uncontrolled air leakage through the relevant parts of the building envelope.

This can help reduce the loss of conditioned air, unwanted air infiltration and avoidable demand on heating and cooling systems.

Depending on the project and applicable provisions, the documentation may need to address:

• openable windows;
• external doors;
• door-edge and threshold seals;
• self-closing doors;
• main entrances to conditioned spaces;
• loading-dock entrances;
• roof lights;
• exhaust fans and dampers;
• service penetrations;
• construction joints;
• interfaces between façade systems; and
• continuity around the conditioned envelope.

The applicable sealing requirements include exceptions and jurisdictional variations. The correct response should therefore be checked against the project classification, climate zone, building use and adopted NCC provisions.

A general note stating that the building must be sealed is less useful than coordinated door schedules, window specifications and details showing how the requirement is intended to be achieved.



Operable windows and doors forming part of the envelope may require appropriate sealing.

The design response can depend on the type of opening, its location, the climate zone and any applicable exception.

The project team should coordinate:

• door seals and threshold details;
• window sealing and relevant product standards;
• door closers;
• airlocks or other entrance arrangements where applicable;
• rapid roller or similar doors where relevant;
• interfaces between doors, frames and surrounding walls;
• fire and smoke-door requirements;
• accessibility requirements;
• waterproofing and weather protection; and
• mechanical pressurisation or ventilation strategies where relevant.

Energy-efficiency requirements should not be documented in isolation from fire safety, accessibility, security, acoustic and operational needs.

The Section J response should identify the required outcome while the architectural and services consultants coordinate the complete doorway or opening design.



The nominal performance of walls, roofs and floors can be undermined where insulation or sealing is interrupted repeatedly.

Areas requiring coordination may include:

• roof-to-wall junctions;
• wall-to-floor junctions;
• window and door perimeters;
• façade anchors and support systems;
• structural columns and beams;
• service penetrations;
• ductwork and pipework openings;
• electrical and communications entries;
• exhaust and intake openings;
• movement joints; and
• transitions between different façade systems.

Not every junction requires a separate Section J calculation, but the design should avoid obvious gaps between the assessed thermal and sealing strategy and the proposed construction.

Details relied upon for insulation continuity should remain compatible with structure, fire resistance, moisture management, acoustic performance and constructability.

Where a junction cannot be resolved as assumed, the project team should advise the Section J assessor before substituting a different construction response.

A Section J Report documents the assessment, but the project team still needs to incorporate the relevant measures into the approval and construction documentation.

Fabric, glazing and sealing requirements may need to appear in:

• floor plans;
• elevations;
• building sections;
• roof plans;
• wall-type schedules;
• roof and floor schedules;
• window and glazing schedules;
• door schedules;
• façade details;
• insulation schedules;
• architectural specifications;
• mechanical documentation; and
• relevant construction notes.

The report, drawings and schedules should refer to the same design revision.

For example, a glazing U-value and SHGC stated only in the Section J Report may be missed during procurement if the architectural glazing schedule contains different or incomplete requirements.

Likewise, insulation shown only in a general specification may be overlooked if the wall or roof details do not identify its location.

For the complete project-information checklist, read What Documents Are Needed for a Section J Report?



Many fabric and glazing issues are caused by inconsistent information rather than by one obviously unsuitable product.

Common coordination problems include:

• conditioned areas differing between architectural and mechanical drawings;
• window sizes differing between elevations and schedules;
• glazing performance values relating only to the glass rather than the complete system;
• wall types that omit framing, cavities or linings;
• insulation that cannot fit within the nominated construction;
• missing shading dimensions;
• spandrel panels being recorded as transparent glazing;
• glazed doors or shopfronts being omitted;
• building-sealing notes not appearing in the door or window schedules;
• the report and drawings referring to different design revisions; and
• product substitutions being made without reassessment.

These problems can affect the calculation, the approval package and the ability of the builder to identify what must be constructed.

For the wider design and documentation review, read 7 Common Section J Compliance Mistakes and How to Avoid Them.

This guide focuses primarily on coordinating fabric, wall–glazing construction and sealing within a Deemed-to-Satisfy context.

Some buildings may not align efficiently with the prescribed DTS provisions. This can occur where the project includes extensive glazing, complex façade geometry, multiple orientations, unusual construction systems or strong architectural constraints.

In those cases, the project team may consider whether JV3 modelling or another Performance Solution is appropriate.

JV3 does not remove the need for accurate envelope information. The model still requires reliable geometry, conditioned zones, construction assemblies, glazing systems, shading and relevant services inputs.

It should also not be assumed that any weak façade decision can be offset by an unrelated efficient system. The applicable modelling rules and envelope safeguards still need to be satisfied.

For the complete pathway comparison, read Section J DTS vs JV3: Which Pathway Suits Your Project?



1. Confirm the envelope boundary. Check that conditioned and unconditioned areas are consistent across architectural and mechanical documentation.
2. Identify every relevant construction type. Roofs, ceilings, walls and floors forming the envelope should be clearly tagged.
3. Document complete construction build-ups. Include framing, cavities, insulation, cladding, linings and other relevant layers.
4. Confirm that insulation is buildable. Check available cavity depth, services, framing and junction conditions.
5. Coordinate glazing areas. Window and glazed-door dimensions should match between plans, elevations and schedules.
6. Use complete-system glazing values. Confirm the U-value and SHGC for the proposed glass-and-frame system.
7. Check orientations. Make sure openings are assigned to the correct façade or aspect.
8. Dimension shading elements. Any shading relied upon in the assessment should appear in the final drawings.
9. Document building sealing. Coordinate windows, doors, entrances, penetrations and relevant exhaust openings.
10. Use one current design revision. The report, drawings, schedules and specifications should describe the same project.
11. Resolve provisional assumptions. Replace preliminary values with confirmed selections before final issue where required.
12. Review material substitutions. Changes to glazing, insulation, façade systems, doors or sealing details should be checked against the assessment.



Is double glazing required for Section J?

Not automatically. The required glazing response depends on the complete system performance, glazed area, frame, façade orientation, shading, wall construction, climate zone and selected compliance pathway. Some projects may comply with suitable single glazing, while others may require higher-performing systems.

Are walls and glazing assessed separately?

Under the NCC 2022 DTS provisions, relevant walls and glazing are assessed together as wall–glazing construction. The combined response considers the opaque wall and glazed portions of the façade rather than treating each window as a completely isolated element.

What is a Total System U-Value?

A Total System U-Value describes the rate of heat transfer through the complete assessed system. For glazing, the relevant value generally includes both the glass and frame rather than the centre-of-glass result alone.

Does the window frame affect Section J compliance?

Yes. Frame material and design can affect the complete-system U-value. Two windows using the same glass can produce different system performance when different frames are used.

Can external shading improve the façade result?

External shading can reduce solar exposure to glazing and may improve the façade response. The effect depends on the orientation, glazing geometry and permanent dimensions of the shading element.

Can internal walls form part of the building envelope?

Yes. An internal wall may form part of the envelope where it separates a conditioned space from an unconditioned space, such as a warehouse, plant room, car park or another relevant building area.

What building-sealing details are commonly needed?

Depending on the project, the documentation may need to address seals to operable windows and external doors, door closers, conditioned entrances, loading-dock openings, exhaust dampers, service penetrations and construction joints.

Can glazing be substituted after the Section J Report is issued?

A glazing system may be substituted where the replacement maintains the performance and other characteristics relied upon in the assessment. The complete-system U-value, SHGC, frame and relevant product configuration should be checked before procurement or installation.

Is the insulation product R-value the same as the wall Total R-Value?

Not necessarily. The completed wall includes other layers, cavities, framing and thermal paths. The product R-value describes the insulation itself, while the assessment may require the thermal performance of the complete construction system.

Does the Section J Report replace façade or mechanical design?

No. The report documents the energy-efficiency compliance response within its agreed scope. Detailed façade engineering, structural design, waterproofing, fire, acoustic and mechanical design responsibilities remain with the relevant project consultants.

Documents Needed for Section J

Review the architectural, glazing, construction and services information needed for an early review or final report.

Common Section J Mistakes

See which scope, documentation, façade and services errors commonly lead to corrections and revised reports.

Section J DTS vs JV3

Compare the prescribed and modelling-based pathways where a complex façade does not resolve efficiently through DTS.
