Residential DTS Non-Compliance: What Are Your Options? | Certified Energy

If a residential design does not satisfy an applicable elemental DTS requirement, the relevant building element or assessment input must be reviewed before compliance can be established through that provision.

The project team may be able to revise the design, change a product specification or correct incomplete documentation to demonstrate compliance.

Where the proposed design cannot satisfy the relevant elemental provisions, another recognised NCC compliance method may need to be considered, provided it is applicable to the building classification, project and jurisdiction.

A shortfall in one prescribed requirement cannot automatically be offset by better performance elsewhere unless the relevant NCC provision or compliance method expressly permits that approach.

For an overview of the elemental compliance framework, visit the Residential DTS Knowledge Hub.



Deemed-to-Satisfy provisions provide prescribed methods of satisfying relevant NCC Performance Requirements.

For residential energy efficiency, the applicable elemental provisions establish requirements for particular building elements, construction systems and assessment conditions.

Where the proposed design does not satisfy one of these requirements, compliance has not been demonstrated through that particular provision.

This is different from concluding that the entire building is incapable of satisfying the NCC.

The issue may arise because:

• the proposed building element does not achieve the prescribed performance;
• the selected product does not meet a relevant specification;
• the building geometry or glazing configuration falls outside the permitted assessment conditions;
• a required construction or sealing detail has not been addressed;
• the wrong climate-zone or construction assumptions have been used; or
• the documentation does not provide sufficient evidence to establish compliance.

These situations are not necessarily equivalent. A technical shortfall may require a design change, while missing information may be resolved through additional documentation.

The first step is therefore to identify the relevant NCC provision, the assessment input and the reason compliance has not been demonstrated.

A clear explanation of the specific issue allows the project team to consider appropriate next steps without treating the entire design as non-compliant by default.



Elemental DTS issues can arise across several parts of the residential building envelope.

The nature of the issue depends on the applicable provision, climate zone, building configuration and proposed construction specifications.

Areas that may require further review include:

• Glazing: Window area, total-system U-values, solar heat gain coefficients, orientation or recognised shading conditions.
• Roof and ceiling construction: Prescribed thermal resistance, roof construction details or relevant solar absorptance conditions.
• External walls: Insulation specifications, construction assemblies and relevant thermal bridging requirements.
• Floors: Applicable floor insulation, slab or suspended-floor provisions.
• Building sealing: Required sealing measures for relevant openings, penetrations, exhaust fans or construction junctions.
• Documentation: Missing product information, inconsistent drawings or specifications that do not establish the assessed construction.

A design may satisfy several elemental requirements while requiring further work on only one component.

For example, the proposed roof and wall insulation may satisfy the applicable provisions while the glazing configuration requires additional assessment or modification.

In that situation, the review should identify the specific glazing issue rather than assuming that unrelated building elements must also be redesigned.

For detailed glazing considerations, see Residential DTS Glazing Requirements. For building-fabric provisions, see Residential Insulation Requirements Under DTS.



Where an elemental requirement is not satisfied, revising the relevant design element or construction specification may provide a practical way to establish compliance.

The appropriate revision depends on the specific provision and the reason the original design did not satisfy it.

Potential revisions may include:

• selecting a window system with suitable thermal performance characteristics;
• adjusting glazing dimensions or configurations;
• reviewing fixed shading arrangements where relevant to the permitted glazing calculation;
• changing an insulation product or construction assembly;
• revising roof or ceiling specifications;
• addressing required thermal break or thermal bridging details;
• including missing building sealing provisions; and
• correcting documentation that does not accurately describe the proposed construction.

A proposed revision should be checked against the relevant elemental provision before it is treated as an acceptable solution.

For example, selecting a glazing product with a lower U-value may improve one relevant thermal characteristic, but the complete glazing assessment may also depend on solar heat gain, orientation, area and shading.

Similarly, replacing insulation with a product of higher nominal R-value does not necessarily resolve every requirement affecting the complete construction assembly.

The objective is to demonstrate that the revised design satisfies the applicable provision, not merely that an individual product appears to offer better performance.

Where revisions are made after an earlier assessment, the supporting compliance documentation should also be reviewed. See What Happens When Plans Change After a Residential DTS Assessment?.



Elemental DTS compliance is based on satisfying the requirements and assessment methods prescribed by the relevant provisions.

A project team should not assume that exceeding one requirement automatically compensates for failing another.

For example, additional roof insulation does not, by itself, establish compliance where a separate glazing requirement has not been satisfied.

Some prescribed assessment methods may provide flexibility within their own calculation framework. Where that flexibility exists, it must be applied according to the conditions and limits of the relevant provision.

This is different from introducing an unrestricted trade-off between unrelated building elements.

When considering a proposed adjustment, the assessor should establish:

• which specific DTS provision applies;
• whether the provision includes a recognised calculation or adjustment method;
• which building elements and inputs that method covers;
• whether the proposed design remains within the permitted assessment conditions; and
• what evidence is required to demonstrate compliance.

If the proposed approach cannot be demonstrated under the applicable DTS provisions, a different recognised compliance method may need to be considered.

The distinction is important because a design improvement and a valid compliance demonstration are not necessarily the same thing.



Another compliance pathway may be worth considering where the proposed design cannot satisfy an applicable elemental DTS requirement without changes that are impractical or inconsistent with the project's objectives.

This does not mean that an alternative method is automatically available or that it will necessarily demonstrate compliance.

The relevant NCC Performance Requirements must still be satisfied through an appropriate recognised compliance approach.

A pathway review may be appropriate where:

• a proposed building element cannot satisfy the relevant prescribed requirement;
• the design relies on a configuration not accommodated by the selected elemental method;
• repeated design revisions have not resolved the identified issue;
• the selected construction system requires a different compliance demonstration;
• the building classification changes which provisions apply; or
• the project team needs to establish whether another recognised assessment approach is suitable.

The review should identify the applicable Performance Requirements, the available compliance methods and the evidence needed for the proposed approach.

In some cases, retaining the elemental pathway and making a targeted design revision may remain the simplest option.

In others, a different recognised assessment method may be more appropriate, subject to the applicable NCC and jurisdictional framework.

The decision should be made on the basis of project suitability and regulatory requirements rather than assuming that one pathway is universally easier or more flexible.



Residential energy-efficiency compliance can involve different assessment methods, but their purpose, scope and regulatory application should not be confused.

The appropriate method depends on the building classification, relevant NCC Performance Requirements and the provisions applying to the project.

NatHERS-based assessment

NatHERS uses accredited assessment software and defined protocols to assess residential thermal performance.

A NatHERS-based compliance approach may be available where recognised by the applicable NCC and jurisdictional requirements.

It should not be assumed that obtaining a NatHERS rating automatically resolves every energy-efficiency obligation or permits every proposed design configuration.

Verification Using a Reference Building

Verification Using a Reference Building, commonly referred to as VURB, is a reference-building assessment approach that may be relevant where permitted by the applicable NCC framework.

Rather than demonstrating compliance solely through individual prescribed elemental specifications, a reference-building method assesses the proposed design according to its defined verification conditions.

Its applicability, calculation method and documentation requirements must be established for the particular project.

For a focused comparison, see VURB vs DTS: Residential Compliance Pathways.

Performance Solutions

A Performance Solution is a recognised NCC compliance method used to demonstrate satisfaction of relevant Performance Requirements through an appropriate assessment process.

A Performance Solution may address a particular aspect of a building or form part of a broader compliance strategy, subject to the applicable NCC requirements.

It requires an appropriate assessment method, supporting evidence and the necessary documentation. It is not simply an exemption from a DTS requirement.

A project may also use a combination of DTS provisions and Performance Solutions where permitted and appropriately demonstrated.

These approaches should be evaluated on their regulatory applicability and evidence requirements, not treated as interchangeable alternatives whenever an elemental DTS issue arises.



Where an elemental DTS requirement has not been satisfied, the project documentation should identify the issue and the compliance approach ultimately adopted.

The information required will depend on whether the issue is resolved through a design revision, additional evidence or another recognised compliance method.

Relevant documentation may include:

• the applicable NCC edition and building classification;
• the specific DTS provision or Performance Requirement being addressed;
• the original assessment information and identified issue;
• revised architectural drawings or construction details;
• updated glazing or material schedules;
• relevant product performance information;
• revised calculations or technical assessment evidence;
• the documented basis for any alternative compliance method;
• the final specifications relied upon for compliance; and
• any additional information required by the relevant certifier or approval authority.

Where a design revision resolves the issue under the original elemental pathway, the updated documentation should clearly identify the compliant construction or specification.

Where another compliance method is used, the supporting evidence must demonstrate satisfaction of the relevant requirements through that method.

The assessment documents and architectural drawings should describe the same proposed design.

For more information about coordinating approval-stage evidence, see Preparing Residential DTS Documentation for Certifier Review.



A compliance issue cannot be assessed accurately without establishing the regulatory framework that applies to the project.

The relevant DTS provisions and alternative compliance methods may differ according to the adopted NCC edition, building classification and state or territory requirements.

For example, the elemental provisions relevant to a Class 1 dwelling should not automatically be applied to a Class 2 residential development.

Similarly, a compliance approach accepted under one regulatory framework should not be assumed suitable for a different jurisdiction or project approval context.

Before deciding how to resolve an elemental issue, confirm:

• the applicable NCC edition;
• the relevant building classification;
• the project location and NCC climate zone;
• state or territory variations and transitional requirements;
• the energy-efficiency provisions applicable to the project;
• the recognised compliance methods available; and
• the approval and certification requirements affecting the proposed solution.

In New South Wales, applicable BASIX obligations may also need to be considered. Resolving an NCC elemental DTS issue does not automatically establish compliance with separate BASIX requirements.

A clear regulatory starting point helps prevent the project team from pursuing an assessment method that does not apply to the proposed development.

For a more detailed explanation of location-specific requirements, see How NCC Climate Zones Affect Residential DTS Requirements.



• Confirm the applicable NCC edition and jurisdiction.
• Establish the building classification and relevant climate zone.
• Identify the specific elemental DTS provision involved.
• Determine whether the issue is technical or documentation-related.
• Review the relevant assessment inputs and construction specifications.
• Consider whether a targeted design or product revision can resolve the issue.
• Check any proposed adjustment against the permitted DTS assessment method.
• Do not assume unrelated building-performance improvements provide an automatic offset.
• Consider another recognised compliance method only where applicable.
• Confirm the evidence required for the selected compliance approach.
• Update drawings, schedules and technical documentation as needed.
• Coordinate the final compliance evidence with the relevant certifier or approval authority.



What happens if a residential design does not meet DTS?

The relevant issue must be identified and resolved before compliance can be demonstrated through the selected approach. This may involve revising the design, providing additional evidence or considering another recognised compliance method where applicable.

Does failing one DTS requirement mean the whole house fails?

Not necessarily. An unsatisfied elemental provision means compliance has not been demonstrated through that particular requirement. The project may still be able to achieve compliance through an appropriate design revision or another recognised method.

Can I add more insulation to compensate for glazing that does not comply?

Not automatically. Elemental DTS requirements must be satisfied according to their prescribed provisions and assessment methods. Better insulation elsewhere does not, by itself, resolve a separate glazing shortfall unless the applicable compliance method expressly allows the proposed approach.

Can NatHERS be used if a design does not satisfy elemental DTS?

A NatHERS-based pathway may be available where recognised by the applicable NCC and jurisdictional framework. Its suitability must be established for the particular project, and the relevant thermal performance and other energy-efficiency requirements must still be satisfied.

Is a Performance Solution the same as a DTS exemption?

No. A Performance Solution is a recognised compliance method that must demonstrate satisfaction of the relevant NCC Performance Requirements through an appropriate assessment process and supporting evidence.

Should a DTS compliance issue be resolved before construction?

Relevant compliance issues should be resolved and appropriately documented before affected construction work proceeds, in accordance with the applicable approval and certification requirements. This helps avoid relying on specifications or assessment assumptions that have not been demonstrated as compliant.
